Description
- These spindles are primarily designed to use Spindle Mount Wheels (No Hubs)
- Spindle Mount Wheels will bring each wheel in 3/4″ – 1″ PER SIDE, depending on the previous brakes.
- CNC’d (IN HOUSE) Billet Aluminum Spindle with Heat Treated Stainless Steel Spindle Pins
- Includes: Castle Nuts, Keyed Washers, ARP Stainless Steel Caliper Bolts, Steering Arm Bolts, and Cotter Pins
- Must Be Used in Conjunction with Our 6061 Billet Steering Arms (Part# 303) – (Select box when ordering if needed, SAVE $40 when pairing these up!)
- Designed for Drag Race Applications ONLY
- Corrects Front Suspension Geometry and Installed Shock Height on Lowered Vehicles
- Fits Aftermarket SPINDLE MOUNT Disc Brake Setups (NO HUBS): Strange Front Brakes or TBM Front Brakes
- Also Fits Aftermarket HUB STYLE Disc Brake Setups (HUBS 5 x 4.75 GM bolt pattern): Strange Front Brakes or TBM Front Brakes
- Will NOT use existing brakes that fit a factory spindle
- NOTE – For Spindle Mount Wheels ONLY: Based on Strange GT Strut which uses the large bearing (1.250″ and .750″) … NOT Anglia and NOT Strange Ultra Strut which use the small bearing
– Images may not be vehicle specific –
Additional information
| Weight | 12 lbs |
|---|---|
| Dimensions | 12 × 12 × 12 in |
| Vehicle Type | 64-72 Chevelle (A-Body), 67-69 Camaro/Firebird & 68-74 Nova, 70-81 Camaro / Firebird & 75-79 Nova, 77-96 Impala / Caprice (B-Body), 78-88 Malibu (G-Body), 82-02 S10 & Blazer (2WD) |
| Sort by Brand | TRZ Motorsports |
