Housing Side 4-Link Bracket Kit

Description

These brackets have been developed using years of track testing with top running X275 style cars as well as N/T racing elites.

Available in (Choose Style and Size):

1. Mild Steel – 3.00″ and 3.25″ Axle Tubes (3/4″ Adjustments)
2. 4130 Chrome-Moly – 3.50″ Axle Tube (5/8″ Adjustments)

All brackets have the following features:

• 1/4″ Thick Brackets
• 1/4″ Thick Doublers Included
• Adjustment range can accommodate both Small Tires & Big Tires
• Incorporated 1″ ID Upper Mount Support Hole
• Incorporated 1.5″ ID Lower Cross Support Hole
• Incorporated 1-1/4″ Pro-Jack Mount
• Incorporated Anti-Roll Bar Mounts – 3 Locations (Rod-End Side)
• Incorporated Adjustable Shock Mounting on 5/8″ Increments
• Includes – (2) Billet Aluminum Shock Mounts
• Includes – (4 ea) Upper and Lower Doubler Plates
• Includes – (4) Bracket Support Strips
• Includes – (2) 2.25″ Diameter Center Tube Supports
• Designed to use 1/2″ ID x 3/4″ Wide Rod-Ends

*Note* – Dimensional diagram shown is for 4130 brackets. Mild Steel brackets have increased hole spread to 3/4″ and the uppermost and lowermost hole placements are stretched to accomodate this

Hardware is NOT Included.  You may choose from the below (Rod-End Mounts Only):

• Optional – AN Hardware for Housing Side – (4) 1/2 bolts with washers and nylock nuts
• Optional – NAS Hardware for Housing Side – (4) 1/2 bolts with washers and nylock nuts

These Brackets pair great with our Billet Adjustable Frame Mounts – HERE
