High Deflection Adjustable Strut Cup Kit

Description

What to Know

1-3/4” of Weldable Surface Area

2.5″ of Total Cup Height

Allows for 1-7/8” of Ride Height Adjustment (Up or Down) While Maintaining 100% thread engagement

Allows For Up to 30 Degrees of Motion

Weld-In Cups Are Counter Bored & Have a Thicker Wall to Limit Distortion During Welding

Aluminum Inner Threaded Adjusters Are Made of 7075 Aluminum & Are Hard Anodized for Corrosion Resistance

Strut Fitment

Fits Struts With 5/8”-18 Thread & 5/8” or 11/16” Diameter Above Strut Mount Shoulder on Strut Shaft

****Please Verify What You Need With Your Own Struts Before Making an Order****

Spindle Struts

Strange GT & Aluminum Struts Uses 5/8”

Afco / Menscer Spindle Struts Terminator & Terminator SS Uses 11/16”

Afco / Menscer Bolt-In Struts for 79-04 Mustang or 3^rd Gen F-Body Does Not Use Upper / Lower Inserts or Upper Spring Retainers

****THESE DO NOT FIT STRANGE S2041 STRUTS****

Includes

(2) Outer Weld-In Strut Cups

(2) Large Diameter Strut Adjuster Bearing Cups

(2) Aluminum Jam Nuts

(2) Low-Head Upper Coil-Over Spring Retainers (Not Included In Kits For Use w/Bolt-In Struts SKU # 650-127MF)

(1) ½” Drive Socket Wrench Adjustment Tool

(2) COM12T PTFE Lined Spherical Bearings

(2) Spiral Locks

(2) Upper Misalignment Spacers With 5/8”-18 Threads (Not Included In Kits For Use w/Bolt-In Struts SKU # 650-127MF)

(2) 5/8” ID Lower Misalignment Stainless Alignment Inserts (Included Kit SKU # 650-125 For Use w/Strange Spindle Struts)

(2) 11/16” ID Lower Misalignment Stainless Alignment Inserts (Included Kit SKU # 650-126 For Afco / Menscer Spindle Struts)
